| 安装功率 | 0.75 |
|---|---|
| 产地 | 泰州 |
| 电源电压 | 380V |
| 适用范围 | 工业用 |
| 用途 | 折叠 |
| 噪声 | 70db |
| 整机重量 | 1000KG |
| 种类 | 折叠机 |
| 执行质量标准 | 国标 |
| 品牌 | 汇达 |
| 型号 | ZD3300-5Z |
| 加工定制 | 是 |
| 质量认证 | 3C认证 |
| 发货周期 | 3天以内 |
产品说明：
简要说明
1、采用大屏幕点阵液晶显示及智能化控制系统，并且有良好的全中文人机对话界面。
2、在电脑监控下完成5次折叠，纵折和横折次数可按织物幅度、厚度自由编程。
3、采用高智能化的红外线检测系统，取消了传统的机械脉冲计数装置。
4、具有双通道折叠功能，可双倍提高小型布草的熨平折叠能力，降低能耗。
5、运转速度调节范围大，能与各种相应的熨平机匹配。
6、具有自诊断功能，完善的安全保护系统，检测点自保养功能。
7、电脑板采用继电器输出，无需中间继电器，减少了故障点，维修检测方便。
8、各控制组件均采用直流24V低压组件，安全可靠，便于直接维修。
9、各控制阀均采用气动控制，动作迅速可靠，对周围环境无污染。
10、本设备多处装有安全开关，使用安全可靠。
Instruction
1．Adopted big screen and intelligent control system，the machine has interactive function．
2．Five times of folding can be finished under the control of computer．The number of times and the directions of folding can be programmed freely according to the range and thickness of fabrics．
3．The traditional counter of mechanical pulsing has been replaced by infrared testing system of high intelligence．
4．With the function of double channel folding，it can save energy double．
5．The running speed can be adjusted widely to be suitable for various ironing machines．
6．It has the functions of automatic diagnosis，perfect safety system and self-maintenance for testing points．
7．The computer board adopts relay output and there is no intermediate relay．It may reduce troubles greatly，and maintenance becomes easy．
8．All control components use 24V DC．It is not only safety，but also easy to maintain directly．
9．All control valves are controlled by pneumatic system and all actions become quick and reliable．
10．Equipped with several safety switches in different positions．the machine is safe and reliable.
主要技术参数 Main parameter
