晋江市超骏机械有限公司

适用范围：

适用于各种布料、无纺布、泡棉、皮革、纸张、反光材料、醋酸布、补强带、导电布等材料圆包装及各种织物工切捆条前的验布及重复打卷，能卷制成直纹或45度斜纹卷材。配有半圆形放料桶，圆卷或折叠式织物均可使用。

技术参数：

门幅：1.7米（另有2.05米、2.4米、2.8米、3.2米可选）

卷布**大直径：300毫米,也可定制400毫米

**卷布速度：80米/分钟

卷布电机功率：1.5千瓦

小刀片电机功率：0.12千瓦

电源电压：380V/220V可选

外形尺寸:3.6米×1.5米×1.8米

配备特点：

1.采用电子红外线自动对边装置，并可手动左右移位，方便操作，使布匹等材料卷取后，布边缘整齐一致，布料的浪费达到**少。

2.配有张力控制装置，可根据布料种类控制卷布的松紧度。

3.配有强力扩幅装置，布料不会卷边皱纹，对针织面料的效果更好。

4.配有验布灯箱及照明灯架，能准确快速的检查出布的瑕疵。

5..配有米表自动控制装置，可**计量布米长或码长，并自动控制。

6.卷布速度可无级调节速，并可正反转控制，生产效率高，节省人力，单人操作方便。

7.斜纹卷布可在20度至70度之间调节。采用不锈钢布桶**生锈，避免沾污布料。

8.集中电气控制箱,电气元件分布合理,每条线都做有记号，诊断维修简单快捷，不易出故障，控制系统更为可靠.

Application:

For a variety of fabrics, woven, foam, leather, paper, reflective material, acetate cloth, reinforced belt, conductive cloth, and other packaging materials and various round cut bundles of fabric industrial fabric and repeat the test before playing volume can be ruled or 45-degree roll made of twill sheet. Put the barrel with a semi-circular, round roll or fold the fabric can be used.

Technical parameters:

Width:1.7 m (another2.05 m ,2.4 m ,2.8 m ,3.2 m optional)

Winding diameter:300 mm ,400 mm can also be customized

Cloth fastest speed:80 m / min

Winding motor

Power: 1.5 kw

Small blade motor power: 0.12 kw

Supply voltage: 380V/220V optional

Dimensions:3.6 m ×1.5 m ×1.8 m

Feature:

1.infrared auto-edge electronic devices, and manual shift around, easy to operate, and other materials to make cloth take-up, the fabric edge of the neat line, fabric waste to a minimum.

2.With a tension control device, according to the type of control volume cloth fabric tightness.

3.Expander device with a powerful, curling fabric will not wrinkle, the knitted fabric better.

4.With a light box and cloth inspection lighting truss, can be quickly and accurately detect defects in fabric.

5.Meters with automatic control device can accurat

ely measure Bumi length or code lengt**utomatic control.

6.Winding speed can be adjusted speed, and reversing control, production efficiency and save manpower, single easy operation.

7.Twill cloth volume in between 20 degrees to 70 degrees adjustment. Stainless steel cloth bucket, never rust, to avoid contamination of fabric.

8.Focus on the electrical control box, a reasonable distribution of electrical components, mark each line are doing a diagnostic repair quick and easy, not easy to fail, the control system more reliable
