| 产地 | 江苏 |
|---|---|
| 产品类型 | 全新 |
| 机头数 | 1 |
| 驱动形式 | 电动 |
| 适用场所 | 工厂用 |
| 线迹类型 | 厚料机 |
| 线数 | 双线 |
| 用途 | 缝纫设备 |
| 针数 | 双针 |
| 整机重量 | 68 |
| 作用对象 | 塑料 |
| 自动化程度 | 自动 |
| 品牌 | 金垦 |
| 型号 | GB-266-1 |
特点及用途;
1.机器在GB-266的基础上通过全电脑控制，内存200余种花样，通过按钮控制，客户可以根据自己的要求自编花型，并储存在控制面板上，实现一机多用。
☆通过更换机针的型号，机器可以缝制国内外所有的缝线，是的本机器的使用范围更加广泛，更加适合当今的流行趋势。
2.由于本机器是由伺服电机控制，操作更简单，对工人的技术要求不高，适于更多工厂使用。
3.适用于**皮衣、皮鞋、箱包、汽车坐垫、沙发、休闲服、羽绒服、牛仔服等花样缝制。
SPECIAL FEATURES& APPLICATIONS
This machine based on the GB-266,using the computer-setting. More than 200 different kinds of patterns are available ,fancy or special custom patterns can be created and stored on operation panel, which enables this machine can be used in a lot of different areas.
With the changement of needle, the machine can use all kinds of thread in the world, allowing the using of this machine is more extensive and more suitable for today's trend of fluency.
As this machine is controlled by the servo motor, the operation is more simple and less demanding on the skills of workers.suitable for many factories to use.
☆ Its application covers the stitching of high-grade leather wear ,leather shoes,bag&box,cushion,sofa, leisure cloth,feather coat,jean ect.
规格Specifications:
**高缝速 MAX SEWING SPEED : 800 r.p.m
**大缝目 MAX STITCH LENGTH :13.mm
压脚提升 LIFT OF PRESSER FOOT :20mm
使用机针：NEEDLE SYSTEM :DY*3
工作空间 WORKING AREA:320*185mm
